Power stub map

Distro stubs for plazas and halls.

A man in black studies a clipboard beside a silver truss tower with red and gray equipment on dry grass.

Mark each distro drop

Use the power stub map to plot every 16A and 32A take-off across a plaza, hall, or loading zone. Add booth numbers, cable runs, and the nearest DB so riggers, AV, and brand teams are reading the same sheet. For the latest version, send a note through our contact form and name the resource as the power stub map.

Keep one map per venue area rather than cramming an entire festival site onto a single page. That makes it easier to mark generator feeds, municipal points, and no-go routes around public walkways. During load-shedding planning, the split also helps crews separate essential circuits from nice-to-have kit.

Details worth writing down

Note socket type, breaker size, cable length, and who has access to each locked power point. In malls and convention halls, also mark trading hours, back-of-house entry doors, and any restrictions on crossing customer routes with cabling. A clear sheet on print day reduces guesswork when teams arrive from different suppliers.

Cape Town dispatch point

For the latest power stub map, use our contact form and mention the venue, city, and whether the run is for a plaza, hall, or retail launch. Woodstock, Cape Town remains our base for dispatch notes, cable planning, and power layouts used across South African festival and launch sites.

Check the feed before crews arrive

For plazas, halls, and mall atriums, the power stub map works best when the electrical picture is settled before the first crate rolls in. It helps site leads, riggers, and brand teams agree on where power starts, where it must travel, and where it must stay clear of public movement. That makes it easier to plan activations such as walk-through light tunnels, mirror maze installs, and festival gate stacks without last minute changes to cable routing.

Use the map alongside your venue playbook so load-in, strike, and overnight care all follow the same route. In busy South African environments, a simple drawing can save time around generator placement, ballast, cable ramps, and dust and wind protection. If the install is for a night market, museum forecourt, or hotel foyer, the same method still applies: mark the source, the run, and the access points, then keep the drawing easy to read.

Mark the details crews need

A good stub map should do more than show a socket. It should tell crews what they are connecting to, how far the run is, and which areas need extra care when the build starts. Keep the notes short, clear, and practical so people working on site can check them quickly.

  • Mark every 16A and 32A take-off clearly.
  • Show the nearest DB, socket type, breaker size, and cable length.
  • Note no-go routes, trading hours, and back-of-house access points.
  • Record any generator feeds, municipal points, or locked power areas.

If your activation uses ripple pavilions, lantern fields, or a forecourt build, add the venue area name so the right crew arrives with the right cable plan. For references on how these notes fit into broader site preparation, see our builds overview.

Keep each venue area on its own map

One venue area per map keeps planning readable. A plaza, hall, or retail launch zone can each have its own sheet, so there is less confusion when multiple teams are moving through the same site. That approach also helps with overnight care, as the crew can see which circuits stay live and which parts of the install are closed down after trading hours.

Astonishing Studio is based in Woodstock, Cape Town, and works across South African festival and launch sites with showrooms at Tyger Valley, Clearwater, Cresta, Baywest, Pavilion, and Riverside. If you need the latest version of the power stub map for a venue, send a note through our contact form and mention the site area, city, and the kind of activation you are planning. If you are still putting the wider site pack together, browse our resources for more practical planning tools.
